| TECHNICAL DATA: |
|
Light source: |
LED modules |
|
PHOTOMETRY |
| |
|
Protection class: |
I |
|
|
| |
|
IK: |
10 |
|
| |
|
Protection degree: |
IP66, IP67 |
|
| |
|
CRI: |
>80 |
|
| |
|
Power factor: |
>0,97 |
|
| |
|
Long lifetime: |
>70 000 hours L80B10 |
|
| |
|
Colour temperature: |
4000K |
|
| |
|
Ambient temperature: |
od -40°C do +45°C |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
polycarbonate UV stabilized |
|
| |
|
Diffuser: |
polycarbonate UV stabilized |
|
| |
|
Mounting tray: |
galvanized steel sheet, powder painted |
|
| |
|
Clamps: |
stainless steel |
|
| |
|
|
|
|
| MOUNTING: |
|
Light fitting for direct installation with use of brackets. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Voltage: |
230V, 0/50-60Hz |
|
| |
|
Terminal block: |
3x2,5 mm2 (L, PE, N) or 5x2.5 mm2 (L1, L2, L3, PE, N)
|
|
| |
|
|
|
|
| CERTIFICATES: |
|
KDB 15ATEX0049X |
IECEx KDB 20.0003X |
|
| |
|
CNBOP No. 2608/2016 |
|
| |
|
PZH certificate |
|
| |
|
|
|
| PRIZES: |
|
Ist place in the competition for the best product of the Light 2017 fair |
|
