EXL390LED

Ex ec op is IIC T4 Gc
Ex tb op is IIC T70°C or T80°C Db

	Download
	Data sheet
	Manual
	EU Declaration
	ATEX certificate
	IECEx certificate
	Photometry

Explosion proof coffer light fitting with LED modules. Designed to use in zones 21 and2,22 of gas and steam of flammables liquids, as well as combustible dusts and fibers explosion hazard areas. Available also in A3 emergency version.

Technical data

TECHNICAL DATA:	Light source:	LED modules	PHOTOMETRY
	Long lifetime:	>70 000h L₈₀B₁₀
	Protection class:	I
	Colour temperature:	4000K
	Protection degree:	IP65
	Ambient temp.:	from -40°C to +45°C
	CRI:	>80
	Power factor:	>0,97

CONSTRUCTION:	Housing:	galvanized steel sheet, powder painted or stainless steel sheet
	Diffuser:	OPAL PC

MOUNTING:	Luminaire for direct installation in suspended coffered ceilings or optionally on ceiling surface

ELECTRICAL UNIT:	Voltage:	230V, 0/50-60Hz
	Terminal block:	3x2,5 mm² (L, PE, N) or 5x2.5 mm² (L1, L2, L3, PE, N)
CERTIFICATE:	KDB 15ATEX0049X	IECEx KDB 20.0003X
