EXF300LED

Ex eb mb op is IIC T5 Gb
Ex tb op is IIIC T55°C or T70°C Db

	Download
	Data sheet
	Manual
	Photometry
	ATEX Certificate
	IECEx Certificate
	EU declaration

Explosion proof light fitting with LED modules. Designed to use in zones 1,21 & 2,22 of gas and steam of flammables liquids, as well as combustible dusts and fibers explosion hazard areas. Light fitting with ATEX certificate KDB 15ATEX0049X and IECEx cerftificate KDB 20.0003X. Housing made of stainless steel. PC diffuser. Available in emergency version.

Technical data

TECHNICAL DATA:	Light source:	LED modules	PHOTOMETRY
	Protection class:	I
	Protection degree:	IP67
	CRI:	>80
	Power factor:	>0,97
	Long lifetime:	>70 000 hours L₈₀B₁₀
	Colour temperature:	6500K
	Ambient temperature:	od -40°C do +45°C/+55°C/+60°C*
		* depends on execution

CONSTRUCTION:	Housing:	stainless steel
	Diffuser:	PC
	Mounting tray:	galvanized steel sheet, powder painted
	Clamps:	stainless steel

MOUNTING:	Light fitting for direct installation with use of brackets.

ELECTRICAL UNIT:	Voltage:	110-254VAC (50-60Hz), 220-250VDC
	Terminal block:	3x2,5 mm² (L, PE, N) or 5x2.5 mm² (L1, L2, L3, PE, N)

CERTIFICATES:	KDB 15ATEX0049X	IECEx KDB 20.0003X
