Technical specification
| TECHNICAL DATA: |
|
Light source: |
LED modules |
|
PHOTOMETRY |
| |
|
Protection class: |
I |
|
 |
| |
|
Protection degree: |
IP68 |
|
| |
|
CRI: |
> 80 |
|
| |
|
Power factor: |
≥ 0,95 |
|
| |
|
Long lifetime: |
> 70.000h L80B10 |
|
| |
|
Colour temperature: |
6500K or 4000K |
|
| |
|
Ambient temperature: |
od -40°C do +60°C |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
stainless steel sheet, powder painted |
|
| |
|
Diffuser: |
tempered glass or type safety glass, PMMA, PC |
|
| |
|
Mounting tray: |
galvanized steel sheet, powder painted |
|
| |
|
|
|
|
| MOUNTING: |
|
Light fitting for direct installation on ceiling or wall with use of mounting bracket. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Voltage: |
230V, 0/50-60Hz or 24VDC, 0Hz |
|
| |
|
Terminal block: |
3x2.5 mm2 |
|
| |
|
|
|
|
Dimensions
| TYP |
L |
L1 |
L2 |
H |
B |
B1 |
B2 |
| INS352LED-0600 |
790 |
704 |
730 |
80 |
139 |
60 |
85 |
| INS352LED-1200 |
1400 |
1314 |
1340 |
80 |
139 |
60 |
85 |
Types comparison
* power consumption savings of INS350LED light fitting compared to others producers standard T8 light fittings
** power consumption savings of INS350LED light fitting compared to other producers standard T8 light fittings, assuming basing on equal light flux of compared devices
Available configurations
