Technical specification
TECHNICAL DATA: |
|
Light source: |
LED modules |
|
PHOTOMETRY |
|
|
Protection class: |
I |
|
 |
|
|
Protection degree: |
IP65 |
|
|
|
CRI: |
> 80 |
|
|
|
Power factor: |
≥ 0,95 |
|
|
|
Long lifetime: |
> 70.000h L80B10 |
|
|
|
Colour temperature: |
4000K |
|
|
|
Ambient temperature: |
od -25°C do +45°C |
|
|
|
|
|
|
CONSTRUCTION: |
|
Housing: |
powder painted steel |
|
|
|
Diffuser: |
PRISMATIC polycarbonate, UV stabilized |
|
|
|
Mounting tray: |
aluminium |
|
|
|
|
|
|
MOUNTING: |
|
Luminaire for direct installation on ceiling or wall with use of mounting bracket. |
|
|
|
|
|
|
ELECTRICAL UNIT: |
|
Voltage: |
230V, 0/50-60Hz |
|
|
|
Terminal block: |
3x2.5 mm2 |
|
|
|
|
|
|
CERTIFICATE: |
|
PZH certificate |
|
Dimensions

TYP |
L |
L1 |
B |
D |
H |
INS370LED-1200-B4 |
1313 |
1285 |
210 |
50 |
68 |
INS370LED-1200-B8 |
1313 |
1285 |
280 |
50 |
68 |
INS370LED-1500-A2B4 |
1593 |
1565 |
210 |
50 |
68 |
INS370LED-1500-A4B8 |
1593 |
1565 |
280 |
50 |
68 |
Types comparison

* power consumption savings of INS370LED light fitting compared to others producers standard T8 light fittings
** power consumption savings of INS370LED light fitting compared to other producers standard T8 light fittings, assuming basing on equal light flux of compared devices
Available configurations
