| TECHNICAL DATA: |
|
Light source type: |
T8, TCL, T5 |
|
PHOTOMETRY |
| |
|
Lampholder |
G13, 2G11, G5 |
|
 |
| |
|
Protection class: |
I |
|
| |
|
Protection degree: |
IP68 |
|
| |
|
Power factor: |
≥ 0,95 |
|
| |
|
Ambient temperature: |
from -25°C to +50°C |
|
| |
|
IK: |
10 |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
polycarbonate UV stabilized tube |
|
| |
|
Mounting plate: |
galvanized steel sheet, powder painted |
|
| |
|
|
|
|
| MOUNTING: |
|
Luminaire mounted with use of two brackets. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Terminal block: 3x4 mm2 |
|
| |
|
|
|
| CERTIFICATE: |
|
PZH certificate |
|
