Technical specification
| TECHNICAL DATA: |
|
Light source type: |
T8, T5 |
|
|
| |
|
Protection class: |
I or II |
|
|
| |
|
Protection degree: |
IP65 |
|
| |
|
Power factor: |
≥ 0,95 |
|
| |
|
Ambient temperature: |
from -25°C to +50°C |
|
| |
|
IK: |
10+ |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
powder painted stainless steel sheet |
|
| |
|
Diffuser: |
polycarbonate |
|
| |
|
Mounting plate: |
galvanized steel sheet, powder painted |
|
| |
|
|
|
|
| MOUNTING: |
|
Luminaire for direct installation on wall or ceiling. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Terminal block: 4 mm2 |
|
| |
|
|
|
|
| CERTIFICATES: |
|
CNBOP |
|
| |
|
PKP PLK approval |
|
| |
|
accredited >IK10 (IK10+) impact tests |
|
Dimensions
| TYPE |
L |
B |
H |
| INV320-..-SF - 18/14/24 |
760 |
280 |
110 |
| INV320-..-SF - 36/28/54 |
1370 |
280 |
110 |
| INV320-..-SF - 58/35/49/80 |
1670 |
280 |
110 |
Types comparison
RC - recessed version, designed according to client’s special requirements
18/36/58 - T8 fluorescent lamp, G13 lampholder
14/24/28/35/49/54/80 - T5 fluorescent lamp, G5 lampholder
A3 - version with 3h emergency module |
ADDITIONAL INFORMATION
Light fitting suitable to use in tunnels and underground pedestrian aisles. Thanks to it solid and robust construction high mechanical shock resistance is preserved. Special tool is required for uninstallation of light fitting to prevent access to it. |
