| TECHNICAL DATA: |
|
Light source: |
LED modules |
|
PHOTOMETRY |
| |
|
Protection class: |
II |
|
 |
| |
|
IK: |
10+ |
|
| |
|
Protection degree: |
IP65 |
|
| |
|
CRI: |
> 80 |
|
| |
|
Power factor: |
≥ 0,95 |
|
| |
|
Long lifetime: |
> 50.000h L90B50 |
|
| |
|
Colour temperature: |
4000K |
|
| |
|
Ambient temperature: |
from -40°C to +45°C |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
stainless steel sheet, powder painted |
|
| |
|
Diffuser: |
polycarbonate |
|
| |
|
Mounting plate: |
galvanized steel sheet |
|
| |
|
|
|
|
| MOUNTING: |
|
Light fitting designed for direct installation on ceiling or wall. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Voltage: |
230V, 0/50-60Hz |
|
| |
|
Terminal block: |
2x2.5 mm2 |
|
| |
|
Surge protection: |
10 KV |
|
| |
|
|
|
|
| CERTIFICATES: |
|
CNBOP |
|
| |
|
PKP PLK approval |
|
| |
|
accredited >IK10 (IK10+) impact tests |
|
| |
|
ENEC |
|
| |
|
|
|
| PRIZES: |
|
2nd place in the competition for the best product of the Light 2019 fair |
|
