Technical specification
| TECHNICAL DATA: |
|
Light source: |
LED modules |
|
FOTOMETRIA |
| |
|
Klasa ochronności: |
II |
|
 |
| |
|
IK: |
10+ |
|
| |
|
Protection degree: |
IP65 |
|
| |
|
CRI: |
> 80 |
|
| |
|
Power factor: |
≥ 0,95 |
|
| |
|
Long lifetime: |
> 50.000h L90B50 |
|
| |
|
Colour temperature: |
4000K |
|
| |
|
Ambient temperature: |
od -40°C do +45°C |
|
| |
|
|
|
|
| CONSTRUCTION: |
|
Housing: |
stainless steel sheet, powder painted |
|
| |
|
Diffuser: |
polycarbonate |
|
| |
|
Mounting tray: |
galvanized steel sheet, powder painted |
|
| |
|
|
|
|
| MOUNTING: |
|
Light fitting for direct installation on ceiling or wall. |
|
| |
|
|
|
|
| ELECTRICAL UNIT: |
|
Voltage: |
230V, 0/50-60Hz |
|
| |
|
Terminal block: |
2x2.5 mm2 |
|
| |
|
Surge protection: |
10KV |
|
| |
|
|
|
|
| CERTIFICATES: |
|
CNBOP |
|
| |
|
PKP PLK approval |
|
| |
|
accredited >IK10 (IK10+) impact tests |
|
| |
|
ENEC |
|
| |
|
|
|
| PRIZES: |
|
2nd place in the competition for the best product of the Light 2019 fair |
|
Dimensions
| TYPE |
L |
L1 |
B |
B1 |
H |
| INV320LED-0600-..-SF |
760 |
594 |
280 |
90 |
110 |
| INV320LED-1200-..-SF |
1370 |
1240 |
280 |
90 |
110 |
| INV320LED-1500-..-SF |
1670 |
1240 |
280 |
90 |
110 |
Types comparison
* power consumption savings of INV320LED-..-SF light fitting compared to others producers standard T8 light fittings
** power consumption savings of INV320LED-..-SF light fitting compared to other producers standard T8 light fittings, assuming basing on equal light flux of compared devices
Available configurations
